  passive coax cable IP extender ICET001
Product Name:passive coax cable IP extender ICET001
Product S/N:112223494723
Specification:passive coax cable IP extender ICET001
Product Feature:passive coax cable IP extender ICET001
Product Class:08.Transmission System
Quality Rank:
Chat with us:Click to chat via msnClick to chat via skype
Email:Welcome to contact me for the CCTV power supply business!
    Product Description


  • Passive device, no power required,Built-in surge protection
  • Transmit IP Camera signal over existing coaxial cable
  • Transmission distance reaches max up to 100meters at 10/100 Mbps speed
  • Transmission distance max up to 100m/328ft
  • Low cost, easy and simple installation, it's perfect solution for your IP system
  • To extend IP camera signal over existing coaxial cable, used in pairs with RG59 connector


  • Applied Devices: CCTV camera, monitors, DVR,switchers, IP encoders, etc
  • Video Format: PAL, NTSC, SECAM
  • Standard: IEEE802.3 10/100Base-T
  • Bandwidth: 10/100Mbps
  • Impedance: 50Ωto dual 100Ω or 75Ω to dual 100Ω or 93Ω to dual 100Ω
  • Max Distance: 100m/330ft
  • Crosstalk: > 30dB
  • Connector: Female/Male BNC, RJ45 jack
  • Cable: Coax Cable(RG59)
  • Power: No external power required
  • Housing: ABS engineering plastic
  • Body Color: Black
  • Dimensions(LxWxH): 81*29*24mm / 3.19*1.14*0.94in
  • Net Weight: 36.5g
  • Operating Temperature: -20℃~70℃ / -4℉~158℉
  • Relative Humidity: 0~95% (non-condensing)
  • Storage: Temperature: -40℃~150℃ / -40℉~302℉
  • Product Weight: 75g/0.17Lb


  • 1 x Passive IP Extender
  • 1 x User Manual
