 01.Power Supply >> Water Proof Power Supply >> Water Proof Power Supply PKWF12V2.1A

  Water Proof Power Supply PKWF12V2.1A
Product Name:Water Proof Power Supply PKWF12V2.1A
Product S/N:110817236
Specification:DC12V2.1A25.2W
Product Feature:waterproof
Product Class:01.Power Supply
Quality Rank:
Chat with us:Click to chat via msnClick to chat via skype
Email:Welcome to contact me for the CCTV power supply business!
    Product Description
PKWF12V2.1A
IP67 Waterproof power supply
Input: AC100V~240V;
Output: DC12V;
Meet with CCC, CE, UL standardIC design;Over current\Over load\short circuit\over voltage\overheating protection; surge suppressor
Dimension: 54*38*24mm




Model

PKWF12V2.1A


Output
DC voltage

13.8V


Voltage tolerance

±1%


Rated current

1.0A


Current range

0~2.1A


Rated power

25.2W


Ripple&noise

10mvp-p


DCvoltage

13.8V


input
Voltage range
100~240VAC
frequency
47~63HZ
AC current
0.22A/115VAC,0.11A/230VAC
efficiency
88%
Inrush current
Cold start current 0.5A/115VAC,1A/230VAC
Leakage current
<0. 1mA/240VAC
protection

Rated output power110%~150% start over load
Over load
protection

protection mode:AC charging mode: hiccup mode

Working temp,humidity
-10℃~+60℃,20%~90%RH
environment
Storagetemp,humidity
-20℃~+85℃,10%~95%RH non-condensing
safety
Withstand vibration
10~500HZ,2G 10min/1cycle,period for 60

minutes,each axes
Withstand voltage
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:

0.5KVAC
Fitstandard
Isolated resistance
I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC
Safety standard
Compliance to UL60950-1
EMC standard
Compliance to EN55022,CLASSB
others
Dimension
54*38*24mm (L*W*H)

Weight/packing
0.084kg/100pcs/11.6kg/0.033m³/
